3.2. Two Mono Inserts

This configuration introduces two mono inserts. In this example an Eventide dot9 MicroPitch stompbox is being used for Insert 1, and an Eventide H9 Max is being used for Insert 2.

Two Mono Inserts

Fig. 3.3 Two Mono Inserts

  • Connect your guitar to H90 Input 1.

  • Connect H90 Output 1 to your guitar amp.

  • Connect H90 Output 3 to MicroPitch Input.

  • Connect MicroPitch Output to H90 Input 3.

  • Connect H90 Output 4 to H9 Max Input.

  • Connect H9 Max Output to H90 Input 4.

  • Press the Routing Button and turn the Quick Knobs to select where the Inserts will be in the signal path.

  • Check out Insert Routing (Section 6.2.1) for more info.
